Compatibility charts for door closers
These illustrated charts help you match door width, door weight, and mounting constraints to a practical door closer style. Use them alongside the buyer’s guide and installation tutorial to choose an automatic door closer that closes smoothly, latches reliably, and resists wind without feeling hard to open.
Chart 1: size by width and weight (practical mapping)
This simplified chart is a starting point for door closer sizing. It is intentionally conservative: if your door has high friction, a tight latch, heavy seals, or strong drafts, you may need to move up a size or choose a more robust closer.
Illustrated chart image
Replace with your high-resolution chart graphic
Readable table (mobile-friendly)
Quick reference categories
| Door width | Weight class | Suggested closer |
|---|---|---|
| Up to 813 mm (32 in) | Light | Compact adjustable hydraulic |
| Up to 914 mm (36 in) | Medium | Standard surface closer, adjustable |
| 914–1067 mm (36–42 in) | Medium–Heavy | Higher-power closer or parallel arm |
| 1067 mm+ (42 in+) | Heavy | Heavy-duty closer + robust mounting |
This table is for guidance only. Always confirm manufacturer sizing charts for your chosen model.
Chart 2: mounting style fit checks
Mounting style is as important as closer size. The correct configuration depends on frame face depth, door stop position, and how much arm projection you can accept. Use these illustrated fit checks to pick between standard arm, parallel arm, and top jamb configurations.
Best when pull-side mounting is available and arm projection is not a clearance issue.
Good for push-side installs and reduced projection. Confirm frame face dimensions and bracket position.
Useful when the door face is crowded or the top rail is narrow. Template accuracy is critical.
Illustrated mounting comparisons
Replace with diagrams and labeled photos
If the arm hits trim or the stop, change configuration instead of forcing the installation.
