Real installation examples (before and after)

These examples show typical homeowner and light-commercial scenarios using automatic door closers: exterior doors that slam in wind, interior doors that need quiet closing, and doors that would not latch until tuning was corrected. Each story includes a before-and-after photo set and a short “what we changed” checklist.

Follow the install tutorial Choose the right closer

Example stories

Use these layouts as a template for showcasing your own customer installs with high-resolution photos. Each example includes before/after shots and the key configuration choices.

Example 1

Exterior entry door that slammed in wind

A medium-weight insulated door near a stairwell experienced sudden swings and hard closing. The fix focused on mounting stability and backcheck tuning, not just slowing the sweep speed.

Wind control

before photo exterior door without properly tuned door closer — Before: hard swings and slam close

after photo exterior door with door closer properly installed and tuned — After: controlled close and reliable latch

annotated diagram showing backcheck zone and arm position on exterior door closer — Annotated backcheck + arm geometry

What changed

Re-mounted the arm shoe with better anchoring for the frame material.
Tuned backcheck to slow the opening range without a harsh stop.
Balanced sweep speed for smooth closing and set latch speed to finish reliably.

Check compatibility Related fixes

Example 2

Interior door that needed quiet, gentle closing

A hallway door near bedrooms needed smooth sweep speed and a soft latch phase. The closer choice prioritized adjustability and consistent performance rather than high power.

Quiet close

before photo interior door closing too fast — Before: fast close and bounce

after photo interior door with tuned hydraulic door closer — After: smooth sweep and gentle latch

annotated diagram showing sweep and latch zones for quiet closing — Annotated sweep and latch zones

What changed

Slowed sweep speed to remove bounce and reduce noise.
Adjusted latch speed so the door latches without a snap shut.
Verified hinge friction and ensured the door did not rub the frame.

Step-by-step tutorial Ask a question

Example 3

Door closer installed but the door would not latch

The closer was installed neatly, but the final few degrees were too slow and weak to engage the latch. The solution combined latch speed tuning with strike alignment checks.

Latch reliability

before photo door not latching with hydraulic door closer — Before: stops short of latch

after photo door latching properly after adjustment — After: consistent latch engagement

annotated diagram showing latch speed zone and strike alignment — Annotated latch zone + strike check

What changed

Increased latch speed slightly to finish the last 10–15°.
Checked strike alignment and reduced friction at the latch.
Confirmed door was not rubbing the frame near the top corner.

Troubleshooting guide Check sizing

Want your install featured?

Send a short note with door type, closer style, and two photos (before and after). We can help you document what worked, including mounting choice and final tuning settings. 📷

Contact Delvaronia Review the buyer’s guide

What to include

Door material and approximate width/weight
Mounting style (standard, parallel, top jamb)
Main issue you were fixing (slam, latch, noise)
Before/after photos and a close-up of the closer

We do not publish personal addresses. Photos are used for educational guidance only.
